PiezoWave2T
The best just got better! Setting new standards for electronic rehabilitation modality effectiveness, safety, and ease-of-use.
Advantages:
- PW2T is the new benchmark in focused Piezo technology worldwide
- Including our newly designed Elvation HUB with iPad for an improved MyACT treatment
- Now including 12 Hz technology with improved treatment times
- New and advanced T-Mode options
- Best warranty in the industry
- Direct Focusing – a gentle and precise method of generating acoustic compression
- Up to 25% lighter than our previous system
- Engineered in Germany, now assembled in the USA
- Stable Frequency / energy flux density ratio
- Exceptionally low maintenance
Learn more about MyAct!
FOR MORE INFORMATION CALL TOLL-FREE (877) 279-2663
If you would like more information about our products, or would like a representative speak to you about how our lasers can help you improve patient care and increase revenues, please call us at 1-814-754-9997 Click on our Contact Us Page. We’ll be happy to assist you and answer your questions.
Unbeatable reliability
Reliable, powerful, and stable – a technology that does not let you down – this is why our ROI is considered as one of the best in the industry.
Myofascial Acoustic Compression Therapy (MyACT)
A unique, highly effective medical technology that is non-invasive and reduces the need for drugs or surgery.
The PiezoWave2T succeeds at transforming the mechanical energy of soundwaves into biochemical signals in diseased target tissue. This acoustic compression triggers a cascade of cellular and molecular responses through a process called mechanotransduction.
MyACT induced mechanotransduction supports recovery by stimulating microcirculation through the release of nitric oxide (NO), vasodilation and vascular angiogenesis, increased cellular metabolic rates, as well as providing pain relief via the release of substance P and inflammatory mediators.
The process also releases growth factors (blood vessels, epithelium, bones, collagen, etc.) and stimulates lubricin production and stem cells, thus promoting an environment for enhanced healing and a quicker return to normal activities.
Learn more about MyAct!
FOR MORE INFORMATION CALL TOLL-FREE (877) 279-2663
If you would like more information about our products, or would like a representative speak to you about how our lasers can help you improve patient care and increase revenues, please call us at 1-814-754-9997 Click on our Contact Us Page. We’ll be happy to assist you and answer your questions.
T-Mode – An innovative and unique treatment concept
The scientific literature has found that the frequency of stimuli has a relevant impact on mechanotransduction, i.e., the transformation of mechanical stimuli into biochemical signals. Certain frequencies can be specifically used for therapeutic purposes. Therefore, adjustment of the timing and frequency of pulses (T-Modes) can enhance the effectiveness of MyACT.
RAMP
With the RAMP mode, there is a gradual increase in frequency over a defined period of time. The initial frequency and the ultimate frequency as well as the time period during which the frequency increases are defined before starting treatment. It is used for dynamic applications to treat tendons, the musculotendinous junction, and the muscle belly.
BURT
The BURST frequency mode refers to a series of successive pulse packages interrupted by a brief pause. The duration of pulses and pauses and the frequency are defined before starting treatment. The target tissue experiences a constant shift between the stimulus and respite from the stimulus.
Expert Mode
During the treatment, you can individually display the set total energy flux density (mJ/mm2), the set positive peak pressure (MPa), and the remaining treatment time.
Therapy source F7G3
Convenient therapy source with a small focal center
Focal characteristics and areas of application:
- Small and precise focal zone to diagnose and locate pain points
- Acute and chronic pain in muscles, tendons, and fascia due to muscle hardening and trigger points (e.g., in the upper and lower extremities, cervical, thoracic and lumbar spine, shoulder girdle, hip area)
- 30 mm penetration depth at the focal center
- Max. EFD: 0.146 mJ/mm²
Therapy source FBL10x5G2
Linear focus with a large volume and the highest pulse energy
Focal characteristics and areas of application:
- Linear shape of the focal zone ensures a homogenous transfer of energy across the surface, and a dynamic, efficient application along the length of extended structures
- For large myofascial structures that are close to the surface (e.g., myofascial pain and trigger points in the shoulder-arm region (forearm muscles, trapezius muscle), hip/lower back and lower limb-region (e.g., myofascial pain and trigger points in the thoracolumbar fascia, gastrocnemius muscle, or plantar fascia))
- 20 mm penetration depth at the focal center
- Max. EFD: 0.062 mJ/mm²
Rely on our clinical application experience via the ELvation USA HUB
Providing you with detailed information to increase your treatment success.
Hub Assist – Access application videos which include tips on patient positioning, therapy source placement and treatment parameters as well as webinars and podcasts with experienced clinicians sharing their treatment insights. Also, the latest scientific studies and technical information to keep you informed.
- Videos on indications, parameter settings, therapy source and patient positioning, etc.
- Gain insights from experienced PiezoWave2 users via webinars and podcasts
- Brochures on the application and technology of piezoelectric MyACT
- In depth collection of studies exploring clinical application of focused sound as well as its mechanism-of-action
Ready for new challenges
A widening clinical experience and research on the use of focused sound as well as a clear safety profile for various applications puts MyACT and the PiezoWave2T at the top of the list for effective electronic modalities available to rehabilitation clinicians.
Used worldwide by professional sports teams and major university programs, as well as sports oriented private rehab practitioners, the PiezoWave2T gets the job done!
Here are the reasons why:
- Promotes regeneration and self-healing of musculoskeletal syndromes.
- Reduces pain in most of time as little as one treatment providing a faster return to normal activities.
- Provides powerful diagnostic capabilities for locating injuries – knowing where to treat leads to better outcomes.
- Patients provide bio-feedback during treatment – their direct participation in the treatment process leads to improved overall treatment compliance.
Therapy source FBL10x5G2
Linear focus with a large volume and the highest pulse energy
Focal characteristics and areas of application:
- Linear shape of the focal zone ensures a homogenous transfer of energy across the surface, and a dynamic, efficient application along the length of extended structures
- For large myofascial structures that are close to the surface (e.g., myofascial pain and trigger points in the shoulder-arm region (forearm muscles, trapezius muscle), hip/lower back and lower limb-region (e.g., myofascial pain and trigger points in the thoracolumbar fascia, gastrocnemius muscle, or plantar fascia))
- 20 mm penetration depth at the focal center
- Max. EFD: 0.062 mJ/mm²
Learn more about MyAct!
FOR MORE INFORMATION CALL TOLL-FREE (877) 279-2663
If you would like more information about our products, or would like a representative speak to you about how our lasers can help you improve patient care and increase revenues, please call us at 1-814-754-9997 Click on our Contact Us Page. We’ll be happy to assist you and answer your questions.
Basic Principle of Myofascial Acoustic Compression Therapy
A sound approach to treating acute and chronic musculoskeletal pain. Myofascial Acoustic Compression Therapy (MyACT) is widely used in the treatment of acute and chronic pain in muscles, tendons and joints. MyACT describes the use of acoustic waves to target tissue at varying depths to compress and manipulate tissue resulting in a focused and precise deep tissue massage. The results of the mechanical stimulus delivered by MyACT can lead to increased circulation and pain relief– key components in the healing process.
For targeted, non invasive pain relief
Mechanical stimuli affect almost all cellular functions of living tissue such as growth, cell differentiation, cell migration, protein synthesis, physiological apoptosis and tissue necrosis. The acoustic waves generated by the PiezoWave2 converge at a point deep within the soft tissue to produce an intense, extremely short duration compression burst. The focused acoustic compression force is translated to the surrounding tissue like an extremely precise deep tissue massage. The precise targeting of tissue with Acoustic Compression provides healthcare professionals with a tool to positively influence cellular form and function, which can result in pain relief and improved circulation.
Why PiezoWave2T and MyACT are Unique
Other companies providing compression devices to treat musculoskeletal conditions do not utilize sound waves to create the compression. These devices rely on a percussive application to the outer layer of soft tissue with the hope that the resulting pressure will translate through the tissue to the targeted injury. The deeper the targeted structure the higher the impact required to the outer soft tissue layer with diminishing clinical results due to pressure absorption and increased patient discomfort at the point of contact.
PiezoWave2 sends an array of sound waves effortlessly and without sensation through soft tissue to the desired, controlled depth and at that point the sound focuses to create the compression. This results in a more controlled and effective delivery of energy along with greater patient compliance to the therapy.
The two methods of delivery could not be more different and according to clinicians who have used both devices so are the clinical outcomes.
MyACT is not Ultrasound
Ultrasound units delivery thousands of pulses per second in order to vibrate soft tissue sufficient to produce a localized increase in soft tissue temperature. Unlike Ultrasound, the PiezoWave2 produces slow pulses that do not produce a thermal affect. In addition, the PiezoWave2’s slow sound pulses produce soft tissue compression and not soft tissue vibration
MyACT delivers mechanical energy – not light, electrical or thermal energy
- Tenocytes in tendons, fibroblasts in ligaments and skin, osteocytes in bone, chondrocytes in articular cartilage and endothelial cells in blood vessels are mechano-sensitive and respond to mechanical forces
- MyACT targets tissue at varying depths to compress and manipulate tissue
- PiezoWave2 delivers the most energy at a depth that you de ne without being compromised by tissue absorption
PiezoWave2 and MyACT – Benefiting you and your patients
Improving patient outcomes improves the growth of your patient base and your reputation as an informed provider of effective therapies.
According to PiezoWave2 clinicians adoption of MyACT has grown their patient base on an average of 25%.
For more information call toll-free (877) 279-2663
If you would like more information about our products, or would like a representative speak to you about how our lasers can help you improve patient care and increase revenues, please call us at 1-814-754-9997 Click on our Contact Us Page. We’ll be happy to assist you and answer your questions.
PiezoWave 2T– Designs that improve your daily experience and your patient outcomes
Myofascial Acoustic Compression Therapy
The PiezoWave2 has a simple user interface and foot pedal controls that enhance it’s daily use. The control unit recognizes which therapy source is plugged in to provide the appropriate energy spectrum during use Individual settings can be adjusted with just a few keystrokes and via the treatment control foot pedals. The PiezoWave 2 MyACT is designed with an IPad Holder offering you the possibility to attach your IPad to display patient information and treatment charts. You can also download and up-date our MyAct Treatment Protocol App for your Ipad, ensuring that you will continue to receive the latest information on settings and the newest recommendations for the PiezoWave2 MyAct clinical applications. Quickly and online.- Therapy source recognition with Plug & Play.
Focused or linear therapy for pin pointed and macro treatments – the best pressurewave for every indication.
The piezo-electric principle offers an extensive range of configurations. The only one of its kind in the world, the PiezoWave2 allows users to choose between a classic focused therapy source and a linear focused soundwave.
- Focused or linear – the best pressurewave for every indication
- Excellent performance with single-layer and double-layer technology
- Piezo-electric “direct focusing” technology – minimal pain during applications
- Well defined, precise focus – perfect for diagnosis and therapy
- Uniquely durable therapy source
- Finely adjustable penetration depth using interchangeable gel pads
- Independently adjustable penetration depths and energy levels
- Wide range of low energy settings
- Simple operation with App support and Ipad holder
- Plug&Play – therapy source recognition
- Quick therapy start
- Easy to use – uncomplicated operation
- Supported by our Ipad App
- Use of external, supporting Apps
- Always up-to-date
Focused and linear therapy- for pin pointed and macro treatments
The piezo-electric principle offers an extensive range of configurations. The only one of its kind in the world, the PiezoWave2 allows users to choose between a classic focused therapy source and a linear focused soundwave.
MyACT Packages
MyACT Linear 20
Includes:
- PiezoWave2T
- Standard Cart
- Therapy Source FBL (blue)
- Gel Pads
- Ipad with Learning Hub and Trigger Points App
MyACT MultiUse 30
Includes:
- PiezoWave2T
- PW2 Cart
- Therapy Source FBL
- Therapy Source F7G3
- Gel Pads
- Foot Switch
- Ipad with Learning Hub and Trigger Points App
Pictures may differ from actual product / Tablet PC and App not included
Real Bodywork App
Muscle Trigger Point Anatomy
A Reference for the most common trigger points and referral patterns for over 70 muscles. Features 100+ trigger points with their corresponding referral patterns. Each muscle includes the visual referral pattern and point location, plus a written muscle action, referral and comments for each muscle. You can choose to view each muscle individually, or use the zones view to see all the muscles that refer into a specific area, a great help in discovering the source of pain.
Therapy Sources
Focused Piezoelectric Pressure Wave – pin pointed and linear
Piezo ceramic crystals are arranged on a concave transducer in a mosaic pattern. A high-voltage current briefly excites the piezo crystals, causing them to expand simultaneously a few micrometers along their axis to create a pressure wave. The piezo elements are aligned precisely to the therapy focus. The precise, focused, and nonlinear dissemination of the pulse results in steepening at the point of focus, creating a compression event.
The piezo MyACT system does not require an additional reflector. This accounts for the compactness of the therapy source and the precise, well-defined focal zone. Treatment is quiet and virtually pain-free and the technology allows intensity levels to be freely adjusted with almost no impact on focal size. Piezo technology is extraordinarily durable.
Focused therapy source
Linear therapy source
For more information call toll-free (877) 279-2663
If you would like more information about our products, or would like a representative speak to you about how our lasers can help you improve patient care and increase revenues, please call us at 1-814-754-9997 Click on our Contact Us Page. We’ll be happy to assist you and answer your questions.
Specifically designed for myofascial treatments
Richard Wolf GmbH / Germany and Elvation has specifically designed piezo therapy sources that provide low energy / low pressure levels for myofascial and muscloskeletal massage treatment. Piezo-ceramic elements are geometrically arranged on a concave surface so that when they are excited simultaneously by a brief, high-voltage pulse, they expand by a few micrometers to generate a low energy pressure pulse. The piezo elements are precisely aligned so that each pressure pulse generated focuses in a specific area. This precise focusing of the pulse creates an acoustic compression event at the point of focus.
The PiezoWave2 MyACT system provides you with the choice of two piezo therapy sources for this superficial treatment. The Focused Therapy Source for pin-point, focused treatments and the Linear Therapy Source for larger treatment areas.
Advanced technology that is easy to use
- Myofascial Acoustic Compression Therapy is delivered via the hand-held Therapy Source
- MyACT utilizes an intense, short duration acoustic energy wave
- The array of acoustic energy generated by the Therapy Source passes through soft tissue and becomes concentrated (focused) precisely at the desired tissue depth
- Multiple applicator (gel) pads, can be interchanged to adjust the focal point depth of the acoustic wave
to the targeted tissue
Tissue Penetration Depth
The piezo MyACT technology uses interchangeable gel pads which contact the patient to ensure that the acoustic pulse penetrates precisely to the desired depth with as little scattering as possible. These gel pads are used as spacers and change the penetration depth in increments of 5 mm. They accomplish this by drawing the therapy source’s static focal area incrementally superficial or deep respectively. Penetration depths of between 0.5mm and 3 cm are possible, depending on the therapy source.
Unparalleled treatment control
- Quick and easy control over energy delivery, treatment depth and treatment location MyACT is focused deep in tissue to deliver the greatest amount of energy at the desired focal point
- MyACT’s focal point is adjustable to different depth levels in 5mm steps
- MyACT flares the patient’s familiar pain to confirm the area that requires treatment
- Targeting MyACT at varying depths to compress and manipulate tissue results in a focused and precise deep tissue massage
- Myofascial Acoustic Compression Therapy’s influence as a pin-pointed delivery of mechanical stimulus can result in biochemical events that lead to increased circulation and pain relief – key components in the healing process
For more information call toll-free (877) 279-2663
If you would like more information about our products, or would like a representative speak to you about how our lasers can help you improve patient care and increase revenues, please call us at 1-814-754-9997 Click on our Contact Us Page. We’ll be happy to assist you and answer your questions.
Conditions treatable with MyACT
A sound approach to treating acute and chronic musculoskeletal pain. Myofascial Acoustic Compression Therapy (MyACT) is widely used in the treatment of acute and chronic pain in muscles, tendons and joints. MyACT describes the use of acoustic waves to target tissue at varying depths to compress and manipulate tissue resulting in a focused and precise deep tissue massage. The results of the mechanical stimulus delivered by MyACT can lead to increased circulation and pain relief – key components in the healing process. MyACT is widely used in the musculosceletal system such as myofascial dysfunction and pain associated with triggerpoints. Detailed information of indications and containdications are shown in the user manual for the devices – delivered with the product and available at Elvation Inc.
Mechanism of Action
Acoustic pressure waves are characterized by a pressure surge with an extremely short rise time, which is then followed by an exponential drop in pressure and a brief phase of negative pressure. The pressure waves used in MyACT focus or develop in the target tissue at the point where the pain is originating from. The primary means by which pressure waves affect living tissue is based on the transformation of mechanical stimuli into biochemical or biomolecular signals. Described as mechanotransduction.
Precise pain localization – Patient guided pain relief
MyACT helps define where to treat – a unique feature not offered by other treatment modalities. Diagnosis of referred pain and the recognition of the originating pain triggering points can be accomplished using MyACT. Abnormal musculoskeletal tissue can be “flared” with focused MyACT in order to define the areas that require treatment. This process of defining the origins of pain is guided by the patient through verbal feedback to the healthcare professional providing the treatment.
Steps to locate trigger points or orginating sources of pain:
- Place gel pad directly on the patient’s skin without air pockets and initiate the therapy.
- Start with a low intensity setting of approximately 2-7 and progress based on patient feedback on the intensity of their flared pain.
- Confirm with the patient that the flared pain is familiar.
- Search the triggerpoint by moving the therapy source very slowly and with slight changings of the application angle.
- If no pain can be flared increase the intensity slowly. You may also experiment with the depth of penetration by changing the gel pad if you are unable to localize painful areas.
- The goal is to flare a familiar pain being generated by the trigger point/injury. The constant communication between you and the patient will ensure that you remain on the painful area throughout the intended treatment.
Treatment of Triggerpoints, Enthesopathy and soft tissue injury
The linear focusing therapy source is excellent for treating triggerpoints, Enthesopathies and soft tissue injury – providing a controlled, targeted deep massage –like treatment- capable of delivering compression in deeper muscle regions not reachable with palpation. When moving the therapy source around the treatment area, the patient will feel a deep, dull ache that is familiar to the patient as being like the pain their condition produces. The clinician will ask the patient to report when he or she feels the ache and will adjust the output of the device to the appropriate level tolerated by the patient. The clinician will ask the patient to confirm that the therapy source is still creating the ache and may adjust the location of the treatment based on the patient’s feedback. If at anytime the treatment becomes uncomfortable, the patient is instructed to mention this to the clinician and the output is adjusted to a comfortable level. A typical MyACT treatment takes between 10 and 20 minutes.
Intended Use PiezoWave² MyACT:
The intended use of the PiezoWave² covers the Acoustic Compression Therapy only. Any use of the PiezoWave² outside of the intended use, e.g. for ED therapy, is not approved by FDA and must be considered off-label use. Before using the products, we recommend that you do not solely rely on the information presented and that you always read labels, warnings, directions and other information provided with the products.
